Puffed extruder machine snack food machine
puffed corn extruder machine snack food machinePuff corn snack food making machine adopt corn, rice, wheat, oat, barley etc as ingredients to make puffed snack. Through friction of screw and barrel...
Product Description

puffed corn extruder machine snack food machine

Puff corn snack food making machine adopt corn, rice, wheat, oat, barley etc as ingredients to make puffed snack. Through friction of screw and barrel, the grains are cooked in the extruder. Forming is at the die face cutter. The product shape is determined by a combination of the die aperture, including ball, tube, stick, ring, fruit loop, star, wheel and flower etc.




Snacks food Products shapes

This machine can produce different shapes through change the mould.Variety shapes are available for ball, tube, stick, ring, fruit loop, star, wheel and flower and heart shape by adjusting the mould in the extruder.



Raw Material

Corn, rice, millets, wheat, oat, barley etc as ingredients. The effect will be much better if  the materials  in powder(flour) or grits form.




Model

Capacity

(t/h)

Main power

(kw)

feed power

(kw)

screw dia

(mm)

cutting power

(kw)

45

30kg/h

4.0

0.4

Φ40

0.4

45-A

50kg/h

5.5

0.4

Φ40

0.4

55-A

80kg/h

7.5

0.4

Φ50

0.4

65-A

0.12-0.15

15

0.55

Φ60

0.55

75-A

0.20-0.25

18.5

0.55

Φ70

0.55

85-A

0.25-0.30

22

0.75

Φ80

0.75

95-A

0.40-0.45

37

1.5

Φ90

1.5

100-A

0.50-0.55

55

1.5

Φ100

2.2



Features and Characteristics

1.The snack food machine has the advantage of rational design, high automatic degree and accuracy control.

2. The main body,feeder,contact food parts material is stainless steel, which is easy to be cleaned.

3. The temperature and rotating speed can be controlled and adjusted.

4. We can produce the different products according to the different models (pellet, flower,star , ring  , moon , ball , stick,ainimal or grain )and collocations.

5.The snack food machine has the advantage of rational design, high automatic degree and accuracy control.

6. The main body,feeder,contact food parts material is stainless steel, which is easy to be cleaned.

7.The temperature and rotating speed can be controlled and adjusted.

8.We can produce the different products according to the different models (pellet, flower,star , ring  , moon , ball , stick,ainimal or grain )and collocations.




.jpg

.jpg

Henan Double Elephants Machinery I/E CO.,LTD

A professional collection of research ,design, production and sales of Oil making machine,animal food machine ,extruder machine for pet and snacks,and many other kind of food machine.

Our company has a big manufacturing factory with 40 years rich experiences based on one original machinery started by our government machinery department, we adopts advanced production technology, sophisticated equipment and have won abundant strength after many years of development accumulation.

Our puffed machinery has won the 1999 best national evaluation,and passed the ISO 9001 International Quality Authentication in 2000.More proudly, we have achieved the CE certificate to convenient more European customers.
